“Function description
Support mainstream fast charging such as PD2.0/PD3.0/PPS; QC2.0/QC3.0/AFC/FCP;
Voltage/current real-time monitoring, LED digital indication;
Dual-port independent fast charging.
Product parameters
Material: Zinc alloy+ABS+PC
Size: 73MM*33MM*33MM
Product net weight: about 41.6 grams
Input: DC12-24V
USB port output: 5V-3.4A; 9V-2A; 12V-1.5A (18W Max)
Type-C output: 5V-3.6A; 9V-3A; 12V-2.25A; 20V-2.25A (45W Max)
When 12V voltage input: USB port (18W) + Type-C port (27W), the total output power is 45W (Max)
24V voltage input: USB port (18W) + Type-C port (45W) total output power 63W (Max)
Remarks: 20V output can only be realized when 24V (large truck) voltage input is required.”
